At First Solution Group,  we offer CCTV Camera installation services for businesses and homes.  We offer various affordable packages for every CCTV requirement from our clients.1 Dome CCTV – $400 . 2 Dome CCTV – $550. 3 Dome CCTV – $700. 4 Dome CCTV – $850. Includes Installation and Cabling, DVR and 1 Year Free Warranty

1. Mark the location where you’ll connect the bracket for mounting. Drill the holes then insert raw plugs before putting the bracket on. For wired cameras, you have to thread the wires back through the wall to join it to the monitoring source. Thus, make sure that the holes are big enough to draw the wire through.
2. Attach and secure the camera. Plug the power wire into a socket. Some wireless cameras work without power cards, but you do need to refresh their battery packs.
3. Put the DVR (Digital Video Recorder)in a secure area. We recommend storing it within a lockable enclosure to preserve your surveillance data. Meanwhile, instead of DVRs, wireless CCTV cameras utilize NVRs (Network Video Recorders), which you may install the same manner.
4. Design the cable paths from the cameras to the DVR. If you’re dealing with interior wires, put them below carpets, along skirting boards or near ceiling cornices. For outdoor cameras, use wire mouldings to keep the cables stable and safe from tampering.
5. Plug the network wire to the internet router. IP cameras utilize a Cat 5 or Cat 6 cable, whereas analogue HD cameras require a BNC cable and a DC pin connection.
6. Attach each camera to the DVR or NVR. Finally, connect the DVR to the screen where you want the video stream. We propose utilizing HDMI for the display for a greater resolution.
7. Switch on your CCTV Cameras and DVR or NVR, examine the video stream to determine whether the cameras are recording their intended locations. Modify their angles to allow for blind areas. If certain cameras aren’t operating, check the connections and network clips.Wired CCTV cameras may be tough to install, especially if you know nothing about wiring. For a quick and straightforward installation, go for wireless cameras instead. They rely on wireless receivers to stay connected, so there’s no need for sophisticated cable design. Simply make sure that each camera is inside the main hub’s range.

1. CCTV (closed-circuit television) installation is becoming increasingly common in many public and private spaces, and for good reason. Here are some of the benefits of CCTV installation:
   1. Deterrence of Crime: The presence of CCTV cameras can act as a deterrent to potential criminals, who may be less likely to engage in illegal activity if they know they are being monitored.
   2. Evidence Gathering: If a crime does occur, CCTV footage can provide valuable evidence for law enforcement and prosecution. It can help identify suspects, track their movements, and provide details of the crime itself.
   3. Monitoring of High-Risk Areas: CCTV cameras can be installed in areas that are particularly vulnerable to crime, such as parking lots, alleys, or building entrances. This can help keep these areas under surveillance and reduce the risk of criminal activity.
   4. Remote Monitoring: With the ability to remotely access CCTV footage, security personnel can monitor a space from a remote location. This is particularly useful for large facilities or those with multiple sites.
   5. Improved Safety: CCTV installation can improve the safety of individuals by allowing for rapid response to emergency situations or accidents.
   6. Business Management: CCTV can help with employee management, ensuring that employees are following proper procedures and not engaging in misconduct.
   7. Cost Savings: By preventing crime, reducing the need for security personnel, and providing remote monitoring capabilities, CCTV installation can result in cost savings for businesses and organizations.

   Overall, CCTV installation can provide many benefits for homes, businesses, and communities.

Although wired cameras take longer to set up and involve more work, they are more dependable in terms of surveillance video feed. Wireless security cameras are affordable and easy to install. Yet, there could be drawbacks like network outages, onsite tampering and unreliable video feed due to WIFI instability. Find out more on the pros and cons of wired vs wireless cctv cameras.

If you own your own home, you are allowed to install CCTV cameras inside your property without needing any permission. However, this does not apply to HDB flats. With these cameras, you can monitor your property.

If you’re searching for “CCTV camera installers” or “Hikvision installers” in Singapore, opt for First Solution Group, the best CCTV security systems company in Singapore. With extensive expertise and a proven track record, we deliver reliable solutions tailored to your specific needs. We prioritize quality and durability by sourcing products from top manufacturers.

Our comprehensive services include everything from permit acquisition to post-installation support, ensuring a seamless transition to enhanced CCTV security. Embrace a safer future today by reaching out to First Solution Group for a complimentary consultation, and experience unparalleled security solutions that stand the test of time.

First, Choose the Optimal Spot to Set Up the Camera

The foundation of an effective CCTV system lies not just in the technology itself but in the strategic placement of its components. Before purchasing your CCTV cameras, it’s essential to consider the field of vision each camera will cover. The location you select impacts the effectiveness of your surveillance system significantly. Here’s why choosing the right location is crucial:

• Maximizing Field of View: The chosen location should offer a wide, unobstructed view to maximize the area under surveillance. This ensures comprehensive coverage of your property, enabling you to keep an eye on more with fewer cameras. A well-chosen spot can cover critical areas efficiently, reducing the need for additional cameras and thereby saving on cable length.
• Avoiding Potential Obstructions and Light Interference: To maintain clarity and effectiveness of the footage, avoid placing cameras near bright lights, doors, and windows. Excessive light can degrade picture quality, while obstructions can limit what your cameras can see. It’s crucial to evaluate the environment and choose locations that offer clear, unobstructed views.
• Covering Key Areas: Focus on locations that monitor your property’s most vulnerable points or high-value areas. The ideal spot for an indoor CCTV system might be a corner that overlooks the room’s main entrances, ensuring that anyone entering or exiting the room is captured on video. For outdoor surveillance, a higher vantage point that covers approaches to doors and windows is advisable. This not only enhances security but also acts as a deterrent to potential intruders.
• Convenience and Accessibility: Ensure that the chosen spots for your cameras are not only strategic for surveillance but also convenient for installation and maintenance. Power outlets should be nearby, and the cameras should be placed at least 10ft high to prevent tampering or accidental damage.Remember, the effectiveness of your CCTV system begins with where you choose to place your cameras. Taking the time to plan your setup thoughtfully can significantly impact your system’s success in providing security.

Second Step: Run Wires

Make sure that at each camera position, you have ran one of the supplied pre-terminated cables that is, between the location of the camera and the control equipment (DVR) location.

Things to consider; – The male power plug should be situated at the camera side.

– The power-socket should be situated at the control equipment side.

– Thereafter, for each camera’s video-out socket, link them to a video-input socket that is on the DVR using the black BNC lead on the provided cables.

To manage your wires; – You should design a routing for all your cables starting from the cameras to the DVR device.

– To keep your wire or cables secure and well maintained, utilize wire moldings.

– You should nail the moldings just along the route. In addition, install the Siamese surveillance-wire inside to assist manage the wires.

Step 3: Power Cameras

It is crucial to note that both the DVR as well as the cameras are all powered by a same power source. Therefore, for each CCTV camera’s power-input, connect them to the 4/5/8 way power supply-splitter lead on your power supply using the same cable.

Things to consider; – A camera unit should be put at the appropriate area.

– When installing your cameras; a guide markings should be established for drilling reasons. Drill holes as well as hammer-in the screw moldings to assist install your camera firmly.

– For the camera to operate, you’ll have to plug the camera’s power wire in a socket.

Step 4: Power DVR

Just connect your DVR to the power supply-input which is on the DVR. After it’s done, you may then connect the power supply for DVR, monitor and camera to the main power source.

Things to consider; – All CCTV recording are saved within a DVR therefore it’s crucial to maintain your DVR inside a protected and lockable compartment such that if an intruder occurs to see it then they will be unable to erase the recorded videos.

– This is the most critical phase when it comes to CCTV installation, it ensure a protected security system for your workplace or house.

– It’s crucial to safe-guard your CCTV’s DVR since it’s the area where your surveillance hard disk is stored.

Step 5: Connect your Monitor to the DVR

You may use a BNC-BNC, Scart lead or even a VGA cable to connect your display to the DVR. However, for those utilizing a TFT monitor, it’s vital to follow to your manufacturers’ connecting instructions.

Things to consider; To connect your monitor to the DVR, you’ll have to utilize a video cable to connect through a BNC connection. However, before connecting your BNC port, There are some things you should remember. First, you’ll have to;

– Remove an outer coating of your video cable of around 1.5 cm to reveal the braiding.

– Slide the crimping barrel towards the cable as its bigger diameter facing the cable’s end. Thereafter, you should remove the white insulation that’s protecting the innermost cable.

– Insert the exposed cables into the BNC port as you twist the crimping barrel to make a secure connection.

– You may then connect your DVR-output connection to the screen or monitor to video stream.

Step 6: Program your DVR

This is the final stage when installing a CCTV. Based on the instruction manual, continue with programming your DVR. Some handbook may ask for hard drive installation while some have it already done and you’ll be set to-go. Often, you’ll find instructions on the DVR available on the CD or the booklet offered after purchase.

Things to consider; – Before you start programming your DVR, you have to first, power on your cameras which will then be followed by the display and lastly the DVR.

– Setup your DVR depending on the included user manual with the DVR.

– To validate if each camera is correctly operating and it’s supplying the needed viewing angle, it’s vital to look over on each and every camera’s feed.
